iglidur® D, sleeve bearing, mm

  • Low-cost material with silicone
  • Low coefficients of friction at high speeds
  • For low loads
  • Cost-effective
Product description
iglidur® D | Low-cost material with silicone

  • Low coefficient of friction at high speeds
  • For low loads
  • Very cost-effective
  • Vibration-dampening
  • Very low moisture absorption
  • Lubrication-free and maintenance-free
During the development process of iglidur® D as a bearing material, high performance and low price were the top requirements. In particular, a low coefficient of friction was required at high speeds in dry operation. This material containing silicone achieves a low coefficient of friction in dry operation and runs with virtually no stick-slip.

Typical application areas

Model building
Furniture/Industrial design
Fitness and sports

Further applications can be found here:
Industry solutions


When to use it?
  • When a low coefficient of friction is required
  • For high speeds
  • For low load
  • If you are looking for a very cost-effective bearing
When not to use it?
Use our filter options to find the suitable product

Tolerances and measuring system
The installation height and tolerances of iglidur® plain bearings are dependent on the material and wall thicknesses. For each material, the moisture absorption and the thermal expansion are decisive factors. Plain bearings with low moisture absorption can be designed with a minimal bearing clearance. The rule of thumb for wall thickness: the thicker the wall of the bearings, the larger the clearances must be.
Testing methods

Assembly
iglidur® plain bearings are press-fit bearings. The inner diameter adjusts only after press-fitting into the correctly toleranced housing hole. The press-fit interference can be up to 2% of the inner diameter. This ensures that the bearing is securely press-fitted. Axial or radial movement in the housing are also prevented in this way.
iglidur® - assembling, gluing, machining

Certificates and standards
RoHS compliant
According to 2011/65/EU (RoHS 2)
